Multiplus 48 1600 20-16 Inverter Charger

Features

Description

Uninterrupted Power with Intelligent Energy Management The Victron MultiPlus 48/1600/20-16 is a high-performance, all-in-one power solution that combines a powerful 1600VA true sine wave inverter, a sophisticated 20A adaptive battery charger, and a high-speed 16A AC transfer switch in a single, compact unit.

Designed for ultimate reliability, it ensures a seamless and uninterrupted power supply for a wide range of applications, from off-grid and RV systems to critical backup power. In the event of a grid failure or disconnection from shore or generator power, the MultiPlus automatically takes over the supply to connected loads in less than 20 milliseconds, ensuring that sensitive electronics like computers continue to operate without disruption.

Advanced PowerControl and PowerAssist Technology A standout feature of the MultiPlus is its intelligent power management. The PowerControl feature allows you to manage limited generator, shore, or grid power. You can set a maximum current, and the MultiPlus will prioritize AC loads, using any excess power to charge the batteries, thus preventing overload.

Taking this a step further, the innovative PowerAssist feature enables the MultiPlus to supplement the capacity of the external power source. When peak power is required for a short duration, it instantly compensates by drawing power from the battery, and once the load reduces, it uses the spare power to recharge.

Robust, Reliable, and Ready for Expansion Built with a proven full-bridge plus toroidal transformer topology, the MultiPlus is renowned for its reliability. It is fully protected against short circuits, overloads, and high temperatures. For more demanding applications, the system's capabilities can be expanded.

Up to six MultiPlus units can be connected in parallel to achieve a higher power output. Furthermore, three units can be configured for a three-phase output, offering exceptional scalability. Comprehensive Specifications PowerControl / PowerAssist Yes Transfer Switch 16 A VE.Bus Yes, for parallel and three-phase operation, remote monitoring and system integration INVERTER Input Voltage Range (DC) 38 - 66 V Output Output voltage: 230 VAC 2%, Frequency: 50 Hz 0,1% Cont.

Output Power at 25C (VA) 1600 Cont. Output Power at 25C (W) 1300 Peak Power (W) 3000 Maximum Efficiency (%) 94 Zero Load Power (W) 10 Zero Load Power in Search Mode (W) 3 CHARGER AC Input Input voltage range: 187-265 VAC, Input frequency: 45 65 Hz Charge Voltage 'absorption' (V DC) 57.6 Charge Voltage 'float' (V DC) 55.2 Storage Mode (V DC) 52.8 Max.

Battery Charge Current (A) 20 Battery Temperature Sensor Yes GENERAL Programmable Relay Yes Protection a. Output short circuit, b. Overload, c. Battery voltage too high, d. Battery voltage too low, e. Temperature too high, f. 230VAC on inverter output, g. Input voltage ripple too high Operating Temp.

Range -40 to +65C (fan assisted cooling) Humidity (non-condensing) max 95% ENCLOSURE Material & Colour Steel/ABS (blue, RAL 5012) Protection Category IP21 Battery-connection 16 mm screw terminals 230 V AC-connection G-ST18i connector Weight (kg) 10.2 Dimensions (h x w x d in mm) 470 x 265 x 120
