Grandstream GWN7664ELR Outdoor Wi-fi 6 AX6000 Long-range Access Point

Features

Description

Unleash Blazing-Fast, Long-Range Outdoor Wi-Fi 6 The Grandstream GWN7664ELR is a high-performance 802.11ax Wi-Fi 6 access point designed for medium-to-large businesses and enterprises that require extensive outdoor coverage. It delivers a powerful and reliable wireless solution for various outdoor settings such as stadiums, university campuses, smart city projects, and industrial complexes.

With its weatherproof design and advanced technology, the GWN7664ELR ensures seamless connectivity for a large number of users over a wide area. Key Features: Exceptional Wi-Fi 6 Performance: Experience aggregate wireless throughput of up to 6Gbps, providing ultra-fast speeds for demanding applications.

Extended Coverage: The sophisticated internal antenna design provides a long-range coverage of up to 300 meters, ideal for large outdoor spaces. High-Density Connectivity: Supports up to 512 concurrent Wi-Fi client devices, making it perfect for high-traffic environments. Advanced Technology: Features dual-band 4x4:4 MU-MIMO with OFDMA technology to enhance multi-user efficiency and reduce latency.

Flexible Network Ports: Equipped with a 2.5Gbps RJ45 port and a 2.5Gbps SFP port for versatile and high-speed wired backhaul options. Robust and Weatherproof: The IP67-rated weatherproof casing ensures the access point can withstand harsh outdoor conditions. Simplified Management: Includes a built-in controller that can manage up to 50 local GWN series APs.

It is also supported by GWN.Cloud (free cloud management) and GWN Manager (on-premise software). Enhanced Security: Anti-hacking secure boot and critical data/control lockdown via digital signatures, along with a unique security certificate and random default password per device, provide robust security.

Technical Specifications Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax Antennas 8 individual internal antennas, 4 per band (2.4GHz and 5GHz) Wi-Fi Data Rates 5GHz: 802.11ax: 8 Mbps to 4804 Mbps; 2.4GHz: 802.11ax: 8 Mbps to 1147 Mbps Frequency Bands 2.4GHz radio: 2412 2484 MHz; 5GHz radio: 5180 5825 MHz Channel Bandwidth 2.4G: 20 and 40 MHz; 5G: 20, 40, 80 and 160 MHz Wi-Fi Security WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise, WPA3-Personal, WPA3-Enterprise MU-MIMO 4 x 4:4 2.4GHz (DL/UL), 4 x 4:4 5GHz (DL/UL) OFDMA DL/UL OFDMA Coverage Range Up to 300 meters (984 feet) Maximum TX Power 2.4G: 27dBm; 5G: 25dBm (varies by country/region) SSIDs 32 SSIDs total, 16 per radio (2.4GHz and 5GHz) Concurrent Clients 512 Network Interfaces 1x 2.5G RJ45 Port and 1x 2.5G SFP Port Auxiliary Ports 1x Reset button Mounting Wall mount or pole mount, kits included LEDs 3 tri-color LEDs for device tracking and status indication Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM QoS 802.11e/WMM, VLAN, TOS Network Management Embedded controller can manage up to 50 local GWN APs; GWN.Cloud offers a free cloud management platform for unlimited GWN APs; GWN Manager offers premise-based software controller for up to 3,000 GWN APs Power and Green Energy Efficiency PoE 802.3at; Maximum Power Consumption: 24W Environmental Operation: -30C to 60C; Storage: -30C to 60C; Humidity: 10% to 90% Non-condensing Physical Unit Dimension: 260 x 310 x 59mm; Unit Weight: 1.44Kg Package Content GWN7664ELR 802.11ax Wireless AP, Mounting Kits, Quick Start Guide Compliance FCC, CE, RCM, IC
