| Brand | Acconet. |
| Manufacturer | Acconet. |
Precision Termination for High-Performance Networks The Acconet LC/UPC Fiber Optic Pigtail is a premium-grade solution designed for terminating fiber optic cables with speed and reliability. This 1-meter pigtail features a pre-installed, factory-polished LC connector on one end and an open, unterminated end on the other, making it ideal for fusion or mechanical splicing.
It is engineered to provide a stable and high-performance connection for data centers, telecommunication networks, and FTTH (Fiber to the Home) applications. The single-mode OS2 fiber ensures your network is ready for high-bandwidth, long-distance transmissions with minimal signal loss. Engineered for Excellence and Durability Crafted for professional use, this pigtail utilizes a high-quality zirconia ceramic ferrule in its LC connector, ensuring precise alignment and a secure connection.
The UPC (Ultra Physical Contact) polish minimizes back reflection, providing a more reliable and stable signal compared to standard PC connectors. The 0.9mm tight-buffered cable is designed for easy handling and protection of the fiber core, streamlining the splicing process within fiber optic management equipment like ODFs, terminal boxes, and distribution frames.
Key Features: Factory-Terminated LC/UPC Connector: Ensures a high-quality, low-loss connection with excellent repeatability. Single-Mode OS2 Fiber: Ideal for long-distance, high-speed applications such as 10GbE, 40GbE, and 100GbE networks. Ready for Splicing: The open-ended design is perfect for fusion or mechanical splicing to terminate fiber optic cable runs.
Compact 0.9mm Diameter: Easy to manage within high-density patch panels and enclosures. Broad Application: Suitable for telecommunications, LAN, FTTH, optic fiber sensors, and testing instruments. Technical Specifications Specification Details Brand Acconet SKU AC-FIB-PIGT-LC-UPC Connector Type LC Polish Type UPC (Ultra Physical Contact) Fiber Mode Single-Mode (SM) Fiber Grade OS2 (G.657.A1 / G.652.D compatible) Core / Cladding Diameter 9/125m Insertion Loss 0.2dB (Typical) Return Loss 50dB Cable Diameter 0.9mm Cable Jacket LSZH (Low Smoke Zero Halogen) Length 1 Meter Operating Temperature -20C to +70C Storage Temperature -40C to +85C Compliance IEC, TIA/EIA, RoHS
