Bluesolar Mppt 100 15 Charger Controller VIC-BSC10015-MPPT

Features

Description

Maximize Your Solar Harvest with Ultra-Fast MPPT Technology Unlock the full potential of your solar array with the Victron BlueSolar MPPT 100/15 Charge Controller. By constantly monitoring the voltage and current of your solar panels, its ultra-fast Maximum Power Point Tracking (MPPT) technology ensures that every drop of available power is captured and stored in your batteries.

This advanced system improves energy harvest by up to 30% compared to conventional PWM controllers and by up to 10% compared to slower MPPT models, especially on cloudy days when light intensity is constantly changing. Intelligent Battery Management for Extended Lifespan The BlueSolar 100/15 features the innovative BatteryLife algorithm, an intelligent battery management system designed to extend battery health and life.

If the controller cannot fully recharge the battery in a single day, it raises the load disconnect voltage daily until it successfully achieves a 100% recharge. This process prevents the damaging cycle of partial charging and deep discharging, which can destroy a lead-acid battery in weeks or months.

The intelligent load output also prevents damage from running batteries flat by disconnecting loads at a pre-set voltage. Robust, Flexible, and User-Friendly Engineered for flexibility, the controller automatically selects between 12V and 24V battery systems. It employs a multi-stage adaptive charging algorithm (Bulk, Absorption, Float) to ensure optimal battery care.

For advanced monitoring and configuration, the VE.Direct port allows connection to a PC, a Color Control GX, or a smartphone/tablet via the optional VE.Direct Bluetooth Smart dongle. The unit is built to last, with an IP43 rating for electronic components and comprehensive electronic protections against battery reverse polarity, output short circuits, and over-temperature situations.

Comprehensive Specifications Electrical Specifications Battery Voltage 12/24V Auto Select Rated Charge Current 15A Maximum PV Power, 12V 220W Maximum PV Power, 24V 440W Maximum PV Open Circuit Voltage 100V Peak Efficiency 98% Self-consumption 10 mA Charge Voltage 'Absorption' 14.4V / 28.8V (Adjustable) Charge Voltage 'Float' 13.8V / 27.6V (Adjustable) Charge Algorithm Multi-stage adaptive Temperature Compensation -16 mV / C resp. -32 mV / C Continuous Load Current 15A Protections Battery reverse polarity (fuse), Output short circuit, Over temperature Mechanical Specifications Data Communication Port VE.Direct Operating Temperature -30 to +60C (full rated output up to 40C) Humidity 100%, non-condensing Colour Blue (RAL 5012) Power Terminals 6 mm / AWG10 Protection Category IP43 (electronic components), IP22 (connection area) Weight 0.5 kg Dimensions (H x W x D) 100 x 113 x 40 mm
