HPE Instant On 1960 8-PORT Multi-gigabit Poe+ Switch With 10G Uplinks

Power Your Growing Business with High-Performance, Scalable Networking The HPE Networking Instant On 1960 is an advanced, smart-managed stackable switch designed for small and growing businesses that demand high performance and bandwidth. This powerful and affordable solution is built to handle today's bandwidth-heavy applications like video conferencing and cloud-based services, ensuring consistent, high-speed connectivity.

With a combination of multi-gigabit PoE ports and lightning-fast 10GbE uplinks, this switch eliminates network bottlenecks and future-proofs your infrastructure. Key Features High-Density PoE: Features a massive 480W total PoE power budget to support the latest IoT devices. It includes 8 Gigabit Ethernet ports with Class 4 PoE (up to 30W/port) and 4 multi-gigabit (1G/2.5G) ports with Class 6 PoE (up to 60W/port) for high-power devices like pan-tilt-zoom cameras and advanced access points. 10G Uplink Connectivity: Equipped with two 10GBASE-T copper ports and two 10G SFP+ fiber ports, providing high-speed connections to servers, storage devices, or other switches to eliminate traffic bottlenecks.

Cloud-Managed Stacking: Simplify network management by stacking up to four 1960 switches and managing them as a single entity through one IP address. The Instant On mobile app and cloud-based web portal make setup and remote management incredibly easy. Smart-Managed Layer 2+ Functionality: Get more control over your network with features like Layer 3 static routing, VLANs, Access Control Lists (ACLs), and Spanning Tree Protocol.

Robust Security: Protect your network from unauthorized access with advanced security features including IEEE 802.1X, MAC authentication, Port Security, and automatic denial-of-service (DOS) protection. Comprehensive Specifications Feature Specification Ports 8 x RJ-45 10/100/1000 (1G) Class 4 PoE ports 4 x RJ-45 100M/1G/2.5G Class 6 PoE ports 2 x 10GBASE-T uplink ports 2 x SFP+ 10GbE uplink ports Power over Ethernet (PoE) Total PoE Budget: 480W Class 4 PoE (IEEE 802.3at): Up to 30W per port Class 6 PoE (IEEE 802.3bt): Up to 60W per port Performance Switching Capacity: 116 Gbps Throughput: 86 Mpps Processor and Memory Single Core ARMv7 Cortex-A9 @ 800MHz Management HPE Instant On Cloud; Web browser; SNMP Manager Stacking Up to 4 switches (local and cloud-managed) Layer 2 Features VLANs, Link Aggregation, Spanning Tree Protocol (STP, RSTP, MSTP) Layer 3 Features Static IPv4/IPv6 routing Security IEEE 802.1X, RADIUS, ACLs, Port Security, DHCP Snooping Input Voltage 100 - 240 VAC Dimensions (H x W x D) 4.39 x 44.25 x 35.05 cm (1.73 x 17.42 x 13.80 in) Weight 4.4 kg (9.8 lb) Operating Temperature 0C to 40C (32F to 104F) Warranty Limited Lifetime Warranty
