GPERX4 Outdoor 4-PORT Gigabit Poe Extender & Splitter

Power and Expand Your Network with Ease The MikroTik GPeRx4 is a rugged and compact Ethernet extender designed to dramatically simplify your network expansion. This device expertly splits a single high-power 802.3bt (90W) PoE-in port into three separate 802.3af/at (30W) PoE-out connections. It's the perfect solution for powering multiple cameras, access points, or other devices without needing to upgrade your existing switch.

Effortlessly extend and power your network, even in the most challenging environments. Built for the Outdoors Housed in a robust, IP68-rated enclosure, the GPeRx4 is built to handle tough outdoor conditions. It operates reliably in a wide temperature range from -40C to 70C, ensuring consistent performance wherever you deploy it.

Flexible Powering & Advanced Management The GPeRx4 offers versatile power options, supporting both 802.3bt PoE-in and a 2-pin terminal for direct DC input. For advanced control, the device runs on MikroTik's SwOS Lite. This allows for effortless web-based management, giving you access to interface monitoring, VLAN support, traffic shaping, SNMP reporting, and fault detection for GPEN links. *Please note: This device functions as an extender.

The three PoE-out ports are isolated and only communicate with the first (input) port, not with each other. Technical Specifications General Product Code GPER14i (MT-RBGPERX4) Operating System SwOS Lite CPU 200 MHz Switch Chip Model 88E6341 Storage Size 64 KB Dimensions 281 x 76 x 70 mm Powering Number of DC Inputs 2 (PoE-IN, 2-pin terminal) PoE In 802.3bt PoE In Input Voltage 48-57 V 2-pin Terminal Input Voltage 24-57 V Max Power Consumption 115 W Max Power Consumption (without attachments) 4 W PoE-Out PoE-Out Ports Ether2, Ether3, Ether4 PoE Out Standard 802.3af/at Max Out per Port Output (input > 30 V) 0.6 A Max Total Out 2.0 A Ethernet 10/100/1000 Ethernet Ports 4 Environmental IP Rating IP68 Tested Ambient Temperature -40C to 70C MTBF Approximately 100,000 hours at 25C
