RSD-30H-24 30W Railway Certified Dc-dc Converter

Robust, Reliable Power for Demanding Railway & Industrial Applications Engineered for resilience, the Mean Well RSD-30H-24 is a high-performance 30W enclosed DC-DC converter designed to excel in the harshest environments. It is fully compliant with railway standards BS EN/EN50155 and BS EN/EN45545-2, making it the ideal power solution for rolling stock, railway systems, trams, buses, and other demanding transportation applications.

Its rugged design also suits industrial systems that experience high vibration, dust, and extreme temperatures. Engineered for Performance and Safety The RSD-30H-24 features a 4:1 wide input voltage range of 40-160VDC, accommodating common railway power systems like 72V, 96V, and 110V. It delivers a stable, regulated 24VDC output at 1.25A.

With 4000VDC I/O isolation, this converter ensures system safety and signal integrity. Comprehensive protections, including short circuit, overload, over voltage, and input reverse polarity, are built-in to guarantee operational reliability and longevity. Cooling is achieved through free air convection, allowing it to operate in temperatures from -40C to +70C.

Key Features Compliance with railway standards EN50155 and EN45545-2. Wide 4:1 input range (40 ~ 160VDC). 4000VDC I/O reinforced isolation. Wide operating temperature range (-40C to +70C). Built-in constant current limiting circuit. Comprehensive protections: Short circuit / Overload / Over voltage / Input reverse polarity.

Compact, semi-potted, 1U low profile (25mm) design for vibration resistance. Technical Specifications Specification Details Model RSD-30H-24 OUTPUT DC Voltage 24V Rated Current 1.25A Rated Power 30W INPUT Voltage Range 40 ~ 160VDC Efficiency (Typ.) 88% PROTECTION Overload 105 ~ 135% rated output power; Constant current limiting, recovers automatically after fault condition is removed Over Voltage 27.6 ~ 32.4V; Shut down o/p voltage, re-power on to recover ENVIRONMENT Working Temperature -40 ~ +70C SAFETY & EMC Safety Standards BS EN/EN50155, IEC60571, IEC62368-1, AS/NZS62368.1 I/O Isolation 4KVDC PHYSICAL Dimensions (L x W x H) 113 x 60 x 25 mm Weight 0.25 kg
